[2025 September Tips & Tricks] Revamped Captive Portal for USG FLEX H: Better Security, Less Risk

Zyxel_Avani

📌 Overview

With the release of our next-generation firewall series, Zyxel introduces a key security-driven change in the behavior of the captive portal (web authentication) feature. This update reflects modern security best practices and is designed to reduce potential attack surfaces in your network infrastructure.

🛡️ Background: Legacy Behavior

In ZLD-based (legacy) firewall models, the captive portal was designed to support traffic originating from both:

• LAN (Local Area Network) – typical internal user authentication
• WAN (Wide Area Network) – in some cases, used for remote user authentication

Some customers took advantage of this flexibility and combined captive portal with NAT port forwarding. This allowed users outside the local network (on the internet) to access internal resources via a public IP, with the captive portal acting as a safeguard.

🚨 Security Concern: Increased Attack Surface

While this configuration may seem secure due to the presence of web authentication, it actually poses significant security risks:

• Bypassing Zero Trust principles by exposing internal services to unauthenticated WAN users
• Captive portal is not an encryption-based method—leaving data potentially exposed
• Expands attack surface, making internal resources discoverable from the internet

Such behavior violates industry-standard security best practices and leaves local network environments more vulnerable to exploitation.

⚙️ What’s Changed in the New USG FLEX H Series Firewall

To align with cybersecurity best practices, Zyxel's new-generation firewall products restrict captive portal functionality to LAN-only traffic. In other words:

Captive portal now works only for traffic originating from LAN interfaces. Traffic coming from the WAN is no longer processed by the captive portal.

This change may be inconsistent with the legacy ZLD-based product behavior, but it represents a significant security enhancement aimed at helping our customers build more resilient networks.

👉 Recommended Alternatives: Secure Remote Access

For customers who require access to internal network resources from outside (e.g., remote employees or mobile users), Zyxel strongly recommends using one of the following secure VPN protocols:

• IKEv2 VPN – Ideal for mobile clients and site-to-site tunnels
• SSL VPN – User-friendly and encrypted access through browser or client

These protocols offer end-to-end encryption, strong authentication, and are designed for secure remote access, without exposing internal IPs or services to the public internet.

🔦 What If I Still Need WAN-Based Captive Portal?

If your deployment still relies on WAN-originated traffic being handled by the captive portal (e.g., for public hotspots or legacy integration scenarios), please note:

• This is no longer natively supported in the H series firewall design
• Customers are advised to avoid this approach to maintain security compliance
• If such usage is critical, please contact your Zyxel support representative for further discussion.

💡 Summary

Topic	USGFLEX/ATP series behavior	USGFLEX H series behavior
Captive Portal	LAN and WAN traffic supported	LAN traffic only
WAN Access to Internal Resources	Possible with port forwarding + captive portal, or use VPN (IKEv2, SSL VPN) for secure access	Use VPN (IKEv2, SSL VPN) for secure access

🚀 Need Help?

For migration guidance, remote VPN setup tutorials, refer to these Zyxel Community article👇

https://community.zyxel.com/en/discussion/20029/how-to-configure-remote-access-vpn-with-zyxel-vpn-client
